3 Piece Premium AV-Ventus Actuator Valves

Contact us today to discover how our BV-L3000 Ball Valve can elevate your application! Its low torque requirements facilitate smooth operation, resulting in cost savings by allowing the use of smaller actuators for automating valves that traditionally demand larger ones. The AV-Ventus actuator is distinguished by its unique design, which includes a patented rack and pinion mechanism. This mechanism is notable for its ability to resist wear, avoiding the typical problems of regular use. Remarkably, it achieves this durability without using aluminium, a material often found in similar products.

Key Features

Key features and benefits of the BV-L3000VE, BV-L3100VE & BV-L3200VE Actuated Ball Valves
1

Key Features

The BV-L3000 Ball Valve is well-suited for high-volume pneumatic systems due to its minimal torque requirements. This characteristic reduces the cost of Actuated Valves, as it enables the use of smaller actuators for automating valves that typically necessitate larger ones.
2

Key Features

We handle all product assembly and testing in-house, ensuring complete control over the process and the delivery of a high-quality, long-lasting product to you. Each product is accompanied by a comprehensive two-page test report that includes details on all operational aspects, such as opening and closing times and pressure ratings.
3

Key Features

Featuring a finer teeth module, the actuator in our latest design ensures smoother operation and jerk-free sliding, significantly enhancing overall performance and precision. This refined mechanism allows for a more controlled and accurate movement, minimising vibration and noise during operation.

Valve Standards & Stuff

Body Material: ASTM A351 CF8M 316 Stainless Steel & Trim
Seats Material: TFM 1600 PTFE Ball Seats
Design Standard: MSS SP-110
Wall Thickness: EN 12516-3
Inspection & Testing: MSS SP-110
BSP Ends: (AV-L3000) BSP IS0 7-1 (DIN 2999)
NPT Ends: (AV-L3000) ASME B1.20.1
Socket Weld Ends: (AV-L3100) ASME B16.11
Butt Weld Ends: (AV-L3200) ASME B16.25 (Sch 40)
Pressure Rating: 1000 PSI

FAQs

This valve is appropriate for use with drinking water, provided it falls within the specified pressure and temperature constraints.
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Curabitur scelerisque tincidunt egestas. Donec tempor, lorem eu aliquet imperdiet, nisi tellus imperdiet erat, et ullamcorper nibh diam at orci. Integer placerat arcu pretium, condimentum ante et.

Certainly, our actuated valves are provided with comprehensive operations and maintenance manuals. These manuals are furnished by both the valve and actuator manufacturers.

Yes! Position feedback is provided as a standard feature with switches for both open and closed positions.
Potentially. Contact us so we can discuss potential options.
No unfortunately. We do not offer that level of customisation.
Most definitely. We will require some more information. Drop us an email or get in touch on the blower.
Yes we can. Plane label or with a big bow. Send us a copy of your delivery note and we will fix it to the box. Jop done.
We will need to talk to Big Tony. If he says you're good for the debt then everything is in order. You can apply for this on the product page or ask for Big Tony when you get in touch.
Yes it is. In theory you would need to purchase the valves in quantities of two and we can then re-assemble and pressure test prior to shipping.

Actuation Valve Testing & Calibration

Every actuated valve assembly undergoes thorough testing and calibration by our skilled team of technical engineers before being packed and shipped. This ensures that upon arrival at your location, the assemblies are installation-ready, allowing for swift resumption of your production operations.

Need More Dimensions?

If you lack advanced software or your technical skills are not up to par, don't worry. We provide a comprehensive technical drawing service for our automated valves. Our skilled artists are prepared to create the drawings you require. Just let us know your specifications.
