Multi Voltage PN16 SS AV-ARES Actuator Ball Valves

The BV-A6K00 ball valves, known for their excellence in the industry, have been specifically designed for small to medium-sized control systems with reduced torque needs. This design aims to cut costs and enhance performance by enabling smooth valve operation. If you're planning your next industrial automation project, the AV-ARES Electric Actuator is the ideal solution. This compact and lightweight actuator is easy to install and use, which not only saves you time but also reduces expenses in your valve actuation project. For those seeking an alternative solution, consider our BV-L6K00 Series Actuated Ball Valves. These products offer improved sealing capabilities while simultaneously reducing operating costs due to their low torque requirements.
Shop Help Me

Key Features

Key features and benefits of BV-A6K00AR Actuated Ball Valves.
1

Key Features

The BV-A6K00 Ball Valve proves to be a superb option for high-capacity electric systems due to its minimal torque demands. This leads to cost savings for Actuated Valves, as smaller actuators can efficiently automate valves that typically necessitate more substantial units.
2

Key Features

The valve features a direct mount actuation pad for quick and easy automation. This allows us to get products out of the door to you quicker whilst also reducing the overall footprint of package and most importantly wight and cost.
3

Key Features

The Actuator boasts a robust design, featuring a high-quality aluminium body coated with a black polyethylene finish. This construction ensures protection up to IP67, significantly enhancing its resilience in demanding industrial environments and applications.

Flanged PN40 Technical Data

B C D E Model
1/2" 115.00 181.00 88.00 115.00 AV-A1
3/4" 115.00 186.00 88.00 120.00 AV-A1
1" 115.00 192.00 88.00 125.00 AV-A1
1 1/4" 115.00 269.00 88.00 130.00 AV-A1
1 1/2" 115.00 274.00 88.00 140.00 AV-A1
2" 115.00 283.00 88.00 150.00 AV-A1
2 1/2" TBA TBA TBA TBA TBA
3" TBA TBA TBA TBA TBA
4" TBA TBA TBA TBA TBA
5" TBA TBA TBA TBA TBA
6" TBA TBA TBA TBA TBA

Flanged PN40 3D Models

Actuated Valve Testing & Calibration

All actuated valve assemblies are fully tested and calibrated in house prior to packing and shipping from our expert team of technical engineers. This means that when they arrive at site, you're immediately ready to install and get your production back up and running.

Valve Standards & Specifications
Body Material: ASTM A351 CF8M 316 Stainless Steel & Trim
Seats Material: TFM 1600 PTFE Ball Seats
Body Seal Material: Grafoil/316 Stainless Steel
Stem Packing Material: Grafoil
Design Standard: DIN3357 1,2, EN 12516-1
Wall Thickness: ASME B16.34, EN12516-1
Inspection & Testing: DIN3230/3, EN 12266
Face 2 Face: DIN 3202 F4 (2 1/2" - 4") & DIN 3202 F5 (5" - 8")

FAQs

This valve is appropriate for use with drinking water, provided it falls within the specified pressure and temperature constraints.

Yes. Electric actuators can be supplied with a battery backup or spring return module so the valve moves to a safe position on power loss, and pneumatic actuators can be supplied spring return. Tell us the fail position you need when you enquire.

Certainly, our actuated valves are provided with comprehensive operations and maintenance manuals. These manuals are furnished by both the valve and actuator manufacturers.

It depends on the version. Electric actuators normally include open and closed limit switches. For pneumatic valves, choose the switchbox option to add open and closed position feedback. If you are unsure, contact us and we will confirm.

Potentially. Contact us so we can discuss potential options.

Actuators are supplied in the manufacturer's standard finish. If your application needs a special coating, for example for a corrosive or offshore environment, contact us and we will check what the manufacturer can provide.

Yes. Send us the size, connection, pressure and media by email or call 0151 547 1221 and we will quote a suitable valve and actuator package.

Yes. We can ship on a plain label direct to your customer. Send us a copy of your delivery note and we will include it with the consignment.

Please contact our sales team to discuss account and payment options for your business.

On 3 piece valves, yes. This is done by combining end caps from two valves, so the valves are purchased in pairs; we then re-assemble and pressure test the valve before shipping.

Need More Dimensions?

If you lack advanced software or your technical skills are not up to par, don't worry. We provide a comprehensive technical drawing service for our automated valves. Our skilled artists are prepared to create the drawings you require. Just let us know your specifications.

Valve Rubber Stamps

  • PDF
CERTIFICATES & APPROVALS

PED 2014/34/EU
  • PDF
CERTIFICATES & APPROVALS

ATEX
  • PDF
CERTIFICATES & APPROVALS

Firesafe API 607 5th Ed
  • PDF
CERTIFICATES & APPROVALS

SIL 2
  • Document
CERTIFICATES & APPROVALS

Nace MR-0175
Request more information or Advice

Please feel free to request information and advice using the form below or call us on 0151 547 1221

Stainless Steel PN16 AV ARES Actuator Actuated Ball Valves

(1 Items)
Refine
Hide Filters Show Filters
Sort By
  • Low to High
  • High to Low
  • A to Z
  • Z to A
  • New In
AV Ares Electric Actuated Stainless Steel PN16 Flanged Ball Valve
£259.62
You've viewed 1 of 1 products
