Heavy Duty Carbon Steel AV-ARES Electric Ball Valves

All our Actuated Valve Assemblies are produced in-house with assistance from automation experts. Each finished unit is equipped to meet stringent standards and can be traced through a two-page test report that details opening and closing times. The AV-ARES Valve Actuator features a sturdy manual override lever, providing a reliable mechanical backup in case of a power failure. This safety function enables you to switch between open and closed positions until power or systems are restored. Our team possesses decades of experience in dealing with intricate automation systems, ensuring we can deliver high-quality products promptly and affordably. Just inform us of your requirements, and we'll handle the rest.
Shop Help Me

Key Features

Key features and benefits of BV-A8000FCAR & BV-A8200FCAR Actuated Ball Valves.
1

Key Features

The BV-A8000FC Heavy-Duty Carbon Steel Ball Valve has been specifically crafted for utilisation in demanding industrial settings, where there is a necessity for handling elevated pressures and temperatures. This particular ball valve incorporates PTFE TFM 4215 ball seats for superior sealing, along with a grafoil stem seal and a body made from carbon steel.
2

Key Features

The robust carbon steel ball valves are perfectly suited for applications within industries like chemical processing plants, oil refineries, and water treatment facilities. Thanks to their durable carbon steel construction, you can have confidence that your machinery will maintain dependable performance regardless of the conditions.
3

Key Features

The AR-ARES Electric Actuator can function effectively within a temperature range of -25 to 60 degrees Celsius, maintaining its speed and power efficiency. Its versatility in operating across various environments ensures reliable performance whenever it's required.

Screwed/Socket Weld Technical Data

B C D E Model
1/4" 88.00 176.00 115.00 75.00 AV-A1
3/8" 88.00 176.00 115.00 75.00 AV-A1
1/2" 88.00 176.00 115.00 75.00 AV-A1
3/4" 88.00 184.00 115.00 80.00 AV-A1
1" 88.00 191.00 115.00 90.00 AV-A1
1 1/4" 88.00 261.00 115.00 110.00 AV-A1
1 1/2" 88.00 273.00 115.00 120.00 AV-A1
2" TBA TBA TBA TBA TBA
3" TBA TBA TBA TBA TBA
4" TBA TBA TBA TBA TBA
5" TBA TBA TBA TBA TBA

Screwed/Socket Weld Valve 3D Models

Actuated Valve Testing & Calibration

All actuated valve assemblies are fully tested and calibrated in house prior to packing and shipping from our expert team of technical engineers. This means that when they arrive at site, you're immediately ready to install and get your production back up and running.

Valve Standards & Specifications
Body Material: ASTM A216 WCB Carbon Steel & 304 SS Trim
Seats Material: TFM 4215® (25% Carbon Filled TFM)
Design Standard: MSS SP-110
Wall Thickness: ASME B16.34 Class 800 (1/4" - 1") & 600 (1.1/4" - 2")
Inspection & Testing: MSS SP-110
BSP Ends: BSPP IS0 228/1
Socket Weld Ends: ASME B16.11
Silicone Free: Suitable For Oil Based Paints
Anti Static Device: Ball, Shaft & Valve Body

FAQs

This valve is appropriate for use with drinking water, provided it falls within the specified pressure and temperature constraints.

Yes. Electric actuators can be supplied with a battery backup or spring return module so the valve moves to a safe position on power loss, and pneumatic actuators can be supplied spring return. Tell us the fail position you need when you enquire.

Certainly, our actuated valves are provided with comprehensive operations and maintenance manuals. These manuals are furnished by both the valve and actuator manufacturers.

It depends on the version. Electric actuators normally include open and closed limit switches. For pneumatic valves, choose the switchbox option to add open and closed position feedback. If you are unsure, contact us and we will confirm.

Potentially. Contact us so we can discuss potential options.

Actuators are supplied in the manufacturer's standard finish. If your application needs a special coating, for example for a corrosive or offshore environment, contact us and we will check what the manufacturer can provide.

Yes. Send us the size, connection, pressure and media by email or call 0151 547 1221 and we will quote a suitable valve and actuator package.

Yes. We can ship on a plain label direct to your customer. Send us a copy of your delivery note and we will include it with the consignment.

Please contact our sales team to discuss account and payment options for your business.

On 3 piece valves, yes. This is done by combining end caps from two valves, so the valves are purchased in pairs; we then re-assemble and pressure test the valve before shipping.

Need More Dimensions?

If you lack advanced software or your technical skills are not up to par, don't worry. We provide a comprehensive technical drawing service for our automated valves. Our skilled artists are prepared to create the drawings you require. Just let us know your specifications.

Valve Rubber Stamps

  • PDF
CERTIFICATES & APPROVALS

PED 2014/34/EU
  • PDF
CERTIFICATES & APPROVALS

ATEX
  • PDF
CERTIFICATES & APPROVALS

Firesafe API 607 5th Ed
  • PDF
CERTIFICATES & APPROVALS

SIL 2
  • Document
CERTIFICATES & APPROVALS

Nace MR-0175
