2 Piece Wras Approved Rotork Actuator Valves

The BV4500ROM 2-piece full bore brass ball valve presents an efficient, cost-effective actuated valve solution for screwed and threaded pipelines, also boasting Wras approval for use with potable drinking water. Its ISO 5211 mounting pad enables valve actuation without requiring a mounting bracket, allowing for immediate assembly and testing procedures following your order, with express shipping ensuring delivery of in-stock components within 48 hours. The superior steel gear trains within a liquid process system facilitate correct actuator functioning, guarding against unintended movements. This aspect is vital as, in the event of valve back drive due to power loss, it prevents the potential passage of process media through the valve.
Shop Help Me

Key Features

Key features and benefits of BV-L4500ROM Actuated Ball Valves.
1

Key Features

The Rotork ROM electric actuator includes a manual override function, enabling operators to manually control process movements in situations where power is unavailable or has failed. This crucial safety feature is vital for essential equipment during emergencies, allowing operation to continue without waiting for power restoration.
2

Key Features

Compact, lightweight, and cost-effective, the Rotork ROM electric actuator is ideal for a variety of industrial automation applications. Its design focuses on ease of installation and use, offering time and cost savings for your upcoming projects.
3

Key Features

Using WRAS approved valves helps show that the fittings on your site meet the Water Supply (Water Fittings) Regulations. They address issues related to leaks and wastage that can arise from improper installation, allowing you to fully utilise your system's capabilities.

AV-L4500ROM Ball Valve Technical Data

B C D E Model
1/4" TBA TBA TBA TBA TBA
3/8" TBA TBA TBA TBA TBA
1/2" 114.00 167.00 114.00 59.00 ROM-1
3/4" 114.00 173.00 114.00 69.00 ROM-1
1" 114.00 177.00 114.00 83.00 ROM-1
1 1/4" 114.00 182.50 114.00 94.00 ROM-1
1 1/2" 114.00 194.00 114.00 102.00 ROM-1
2" 114.00 234.00 114.00 124.00 ROM-A
2 1/2" TBA TBA TBA TBA TBA
3" TBA TBA TBA TBA TBA

AV-L4500ROM Ball Valve 3D Models

Wras Approved Actuated Ball Valves

In the UK, water fittings connected to the public supply must comply with the Water Supply (Water Fittings) Regulations, or the Scottish Water Byelaws in Scotland. WRAS approval is not a legal requirement, but it is a widely recognised way of showing that a product has been tested against those requirements. This approval serves as evidence that our products have undergone testing by an independent body to ensure they meet all the necessary standards and requirements established by the government. The AV4500 is a Ball Valve that has received WRAS approval and is suitable for use with drinking water.

SMALL Actuator Data.

  • PDF
DRAWINGS & SCHEMATICS

ROM-1
  • PDF
DRAWINGS & SCHEMATICS

ROM-A
  • PDF
DRAWINGS & SCHEMATICS

ROM-2
  • PDF
DRAWINGS & SCHEMATICS

ROM-3

BIG Actuator Data.

  • PDF
DRAWINGS & SCHEMATICS

ROM-4
  • PDF
DRAWINGS & SCHEMATICS

ROM-5
  • PDF
DRAWINGS & SCHEMATICS

ROM-6
  • PDF
DRAWINGS & SCHEMATICS

ROM-7

Need More Dimensions?

If you lack advanced software or your technical skills are not up to par, don't worry. We provide a comprehensive technical drawing service for our automated valves. Our skilled artists are prepared to create the drawings you require. Just let us know your specifications.

Valve Standards & Specifications
Body Material: Brass CW 617 N
Seats Material: PTFE
Shaft Material: Brass CW 614 N
O-Rings Material: Viton
Ball Material: Brass CW 617 N
Approvals: Wras approved
Mounting: ISO 5211 Connection
End Connections: BSPP
Pressure Rating: PN40

FAQs

This valve is appropriate for use with drinking water, provided it falls within the specified pressure and temperature constraints.

Yes. Electric actuators can be supplied with a battery backup or spring return module so the valve moves to a safe position on power loss, and pneumatic actuators can be supplied spring return. Tell us the fail position you need when you enquire.

Certainly, our actuated valves are provided with comprehensive operations and maintenance manuals. These manuals are furnished by both the valve and actuator manufacturers.

It depends on the version. Electric actuators normally include open and closed limit switches. For pneumatic valves, choose the switchbox option to add open and closed position feedback. If you are unsure, contact us and we will confirm.

Potentially. Contact us so we can discuss potential options.

Actuators are supplied in the manufacturer's standard finish. If your application needs a special coating, for example for a corrosive or offshore environment, contact us and we will check what the manufacturer can provide.

Yes. Send us the size, connection, pressure and media by email or call 0151 547 1221 and we will quote a suitable valve and actuator package.

Yes. We can ship on a plain label direct to your customer. Send us a copy of your delivery note and we will include it with the consignment.

Please contact our sales team to discuss account and payment options for your business.

On 3 piece valves, yes. This is done by combining end caps from two valves, so the valves are purchased in pairs; we then re-assemble and pressure test the valve before shipping.

Actuated Valve Testing & Calibration

All actuated valve assemblies are fully tested and calibrated in house prior to packing and shipping from our expert team of technical engineers. This means that when they arrive at site, you're immediately ready to install and get your production back up and running.

Actuator Equipment

  • PDF
BROCHURES

ROM & ROMpak
  • PDF
OPERATIONS

Installation Manual
  • PDF
CERTIFICATES & APPROVALS

Bureau Veritas
  • PDF
CERTIFICATES & APPROVALS

CSA Certificate Of Compliance
  • PDF
CERTIFICATES & APPROVALS

EU Declaration Of Conformity
